30-2500KVA/10KV Dry Type Epoxy Resin Cast Transformer
Delivery Year: 2023
Country: Singapore
Application Scenario: Data Center High Voltage Distribution Center
Advantages: Full-sealed epoxy resin cast (Epoxy Resin Cast) structure, fire resistance reaches F class, supports 24/7 uninterrupted power supply.
Have questions? GNEE sales representatives are available for live chat now
Send E-mail: sales@gneeelectric.com
Tel: +8615824687445
Henan GNEE Electric Co., Ltd. is one of the most reliable manufacturers and suppliers of 30-2500kva/10kv dry type epoxy resin cast transformer in China. If you're going to buy customized 30-2500kva/10kv dry type epoxy resin cast transformer made in China, welcome to get quotation from our factory. Quality products and reasonable price are available.
Product Overview
Model: Epoxy Resin Cast Dry-type Transformer
Voltage Level: 10KV
Capacity Range: 30KVA – 2500KVA
A dry-type transformer specifically designed for high-voltage and high-reliability scenarios, utilizing fully sealed epoxy resin casting technology suitable for 10KV medium voltage systems. The product meets EU CE certification and UL/IEC global safety standards, perfectly replacing traditional oil-immersed transformers, with wide applications in industrial, rail transport, medical, and power system fields.
Core Advantages of the Dry-type Epoxy Resin Cast Transformer
1. Superior Fire Resistance, Zero-Risk Operation
Fully Sealed Epoxy Resin Casting: No oil or gas emissions from the insulation layer of the dry-type transformer, passing UL94 V-0 flame retardant certification, eliminating fire hazards. Especially suitable for densely populated or flammable environments.
Enhanced Short-Circuit Capability: Mechanical strength increased to 125% of rated load, far exceeding industry standards, ensuring safety for both the epoxy resin cast transformer and the power grid.
2. Green Energy Saving, Reduced Operating Costs
Ultra-Low Loss Design: Copper winding + high-grade silicon steel sheet combination, saving 20% more energy compared to traditional dry-type transformers, meeting IEC60076 efficiency standards.
Environmentally Friendly and Pollution-Free: Oil-free design eliminates leakage risks; operating noise <50dB (under normal conditions), meeting EU RoHS standards, reducing environmental burden.
3. Flexible Adaptation, Comprehensive Scene Coverage
Customizable Capacity and Voltage: Supporting full capacity range from 30KVA to 2500KVA, compatible with voltage levels of 10KV and below, flexibly adapting to diverse needs such as industrial, rail transport, and data centers.
All-Climate Adaptability: Indoor/outdoor installation options available, strong weather resistance, maintaining stable performance under extreme temperatures.
Detailed photos
Technological Innovation of Epoxy Resin Cast Transformer
1. Material and Process Upgrades
Selecting Core Materials: SGS-certified copper wire, high-permeability silicon steel sheets, and high-strength epoxy resin ensure electrical performance and mechanical strength.
Vacuum Casting Technology: Coils and cores are vacuum-cast and solidified to eliminate bubble defects, forming seamless insulation layers that enhance heat dissipation efficiency and lifespan.
2. Intelligent Manufacturing Processes
CNC Winding System: Precisely controlling coil turn errors <0.5%, ensuring efficient heat dissipation and low losses.
Secondary VPI Impregnation Treatment: Reinforcing the transformer's insulation performance and mechanical stability through vacuum pressure impregnation technology.
3. Rigorous Factory Testing
Comprehensive Testing: Withstand voltage test (200% of rated voltage), partial discharge (<10pC), temperature rise test (≤80K), and providing CE and TUV certification reports, committing to zero-defect quality.
Products parameter
Application Scenarios of the Dry-type Epoxy Resin Cast Transformer
Industrial Manufacturing: This dry transformer is suitable for factory production lines and smelting equipment's high-voltage stable power supply, ensuring 24/7 continuous production needs.
Rail Transport: Energy conversion and distribution in subway substations and high-speed rail traction stations, meeting high dynamic load scenarios.
Medical Field: Uninterrupted power supply for operating rooms and laboratories, ensuring safe operation of medical equipment.
Power System: Suitable for urban grid expansion and renewable energy grid integration projects, enhancing power supply reliability and stability.
Commercial Buildings: Emergency power supply and building distribution for large shopping malls and data centers, reducing power outage risks.
video
Customer Value: Lifecycle Cost Optimization
Low Maintenance Costs: No need for regular oil changes or oil quality testing required by oil-immersed transformers, extending maintenance cycles to over 5 years.
Rapid Deployment: Modular design supports quick installation and debugging, shortening project delivery cycles.
Value-Added Assurance: Providing a 10-year warranty, free technical consultation, and fault response, reducing customer concerns.
Why Choose Us?
GNEE Group:Global Transformer Supply Chain Integration Expert (2008 - Present)
Founded in 2008, GNEE Group has undergone fifteen years of deep industry cultivation, successfully transforming from a regional trader to a global supply chain management expert. As a pioneer in the integration of the steel industry chain, the group has established a full-cycle value system that spans raw material procurement, production coordination, logistics optimization, and terminal services, setting an innovative operational benchmark in the global transformer distribution sector. In the era of Industry 4.0, GNEE Group is accelerating towards its goal of becoming a global integrator oftransformer industry value through digital restructuring and green supply chain construction.
Global Certification Endorsement: International certifications such as CE, TUV, RoHS, UL/IEC, meeting global market access requirements.
Customized Services: Adjusting capacity, voltage, installation methods, and optional intelligent monitoring functions based on customer needs.
Local Support: A service network covering the globe with a rapid response time of 48 hours, providing lifecycle technical support.
SGS certification certificate
Our factory
Packing and Delivery
