Henan GNEE Electric Co., Ltd. is one of the most reliable manufacturers and suppliers of s13 1000kva 35kv oil immersed power transformer supplier in China. With abundant experience, we warmly welcome you to wholesale high quality s13 1000kva 35kv oil immersed power transformer supplier at low price from our factory. Contact us for more cheap products.
Product Introduction
S13 1000KVA 35kV oil-immersed power transformer is a high-voltage transformer widely used in power transmission and substation systems in cities, industrial and mining enterprises, rural power grids and power equipment. The transformer has the following characteristics and advantages:
Material and performance: S13 1000KVA 35kV oil-immersed transformer is made of all-copper material, with excellent conductivity and mechanical properties, strong corrosion resistance and long service life. The copper core has good heat dissipation, small temperature rise and high operating efficiency
Application scenario: S13 1000KVA 35kV transformer is suitable for power distribution and conversion of 35KV power grid, and is suitable for various occasions such as high-voltage substations and their distribution stations below. Its low-voltage side rated voltage is 0.4KV, which can meet the needs of different power usage occasions
| Rated capacity: | 1000kVA |
| Voltage combination: | 35kV (customizable) |
| No-load loss: | 830W |
| Load loss: | 10300W |
| No-load current: | 1.0% |
| Short-circuit resistance: | 0.85 |
Structural features: The oil tank of 1000KVA power transformer is composed of corrugated walls, and the surface is dust-sprayed and painted firmly. The corrugated heat sink has cooling and "breathing" functions, which can compensate for the volume change caused by temperature changes, thereby reducing the overall height of the transformer.
Safety design: The S13 transformer is equipped with safety devices such as pressure relief valve, signal thermometer, gas relay, etc. to ensure the safe operation of the transformer. The surface of the oil tank is treated with rainproof, moisture-proof and salt spray-proof, suitable for humid and dirty areas.
Energy-saving effect: The no-load loss of the S13 oil-immersed power transformer is reduced by 40%-50%, the load loss is reduced by 7%-10%, the no-load current is reduced by more than 90%, the noise is reduced by 10-15 decibels, and the power transformation cost is reduced by 17.2%
