1600 KVA 10kV Epoxy Resin Cast Dry Type Transformer Manufacturer

‌‌Product Introduction

1600 KVA 10kV Epoxy Resin Cast Dry Type Transformer‌ is a dry type transformer that uses epoxy resin as the insulation material and has many advantages and features.

‌

1600 KVA epoxy resin cast dry-type transformer‌ Features and functions
‌ High strength and high temperature resistance ‌: High and low voltage windings are cast with epoxy resin, which has high mechanical strength and high temperature resistance, and can effectively resist high temperature and cracking ‌
‌ Low loss and low noise ‌: The core is made of high-magnetic permeability high-quality grain-oriented cold-rolled silicon steel sheets, which reduces no-load loss and no-load current, and reduces core noise ‌
‌ Good insulation performance and short-circuit resistance ‌: Epoxy resin has good insulation performance, can resist short circuit and lightning strikes, and improves the safety and reliability of the transformer ‌
‌ Strong moisture-proof and environmental resistance ‌: The surface of the core is coated with special resin, which is effectively moisture-proof and rust-proof, and can operate normally in a high humidity environment ‌
‌ Perfect temperature protection system ‌: Equipped with a perfect temperature protection control system to ensure the safe operation of the transformer under various working conditions ‌

Wiring method of dry-type transformer
Before wiring, the insulation resistance of the "input" and "output" terminals of the transformer and the ground wire should be tested with a megohmmeter to ensure that the resistance value is greater than 2M ohms
The cross-section wiring of the input and output power lines of the transformer must meet the requirements of the current value. It is recommended to configure it according to the current density of 2-2.5A/min2.
The input and output three-phase power lines should be correctly connected according to the color of the busbar of the transformer wiring board. At the same time, ensure that the neutral line is connected to the neutral neutral line of the transformer. The grounding wire, transformer casing and transformer center point must also be connected.
After completing the wiring, it is necessary to check whether the input and output lines are correct, and observe whether the input and output voltages meet the requirements when powered on without load. If abnormal phenomena such as abnormal noise, sparking, and odor occur, the input power should be disconnected immediately.
After the no-load test is completed and normal, the load can be connected for actual use.
