125kVA Amorphous Metal Transformer
Capacity: 125kVA
Voltage Rating: 11kV/0.4kV
Delivery Year: 2024
Country: Germany
Key Advantages:
70% reduction in no-load loss using Amorphous Metal Transformer technology
Amorphous Steel Core Transformer structure ensures 25+ years of service life
CE-certified with superior environmental performance vs conventional transformers
Have questions? GNEE sales representatives are available for live chat now
Send E-mail: sales@gneeelectric.com
Tel: +8615824687445
Henan GNEE Electric Co., Ltd. is one of the most reliable manufacturers and suppliers of 125kva amorphous metal transformer in China. If you're going to buy customized 125kva amorphous metal transformer made in China, welcome to get quotation from our factory. Quality products and reasonable price are available.
Materials & Craftsmanship of 125kVA Amorphous Metal Transformer
This amorphous transformer features revolutionary manufacturing innovations:
Core Material: Nano-level amorphous steel core transformer alloy, formed by rapid cooling to create disordered atomic alignment, reducing hysteresis loss to 1/5 of silicon steel
Winding Process: Copper foil windings with vacuum pressure impregnation enable stable operation of amorphous core transformers in extreme temperatures (-40℃~120℃)
Structural Design: 3D simulation-optimized amorphous metal transformer housing maintains noise below 45dB
Eco-Friendly Features: Hermetic sealing combined with biodegradable insulating oil complies with RoHS 2.0 standards
Products parameter
| 10KV Series Amorphous Alloy Dry Type Distribution Transformer Performance Parameters | ||||||||||||||||
| High Voltage:10(6,6.3,10.5,11)KV Connection Symbol:D,yn11 or Y,yn0 Rated Frequency:50Hz/60Hz Low Voltage:0.4(0.415,0.433)KV Tapping Range of HV:±2x2.5% Insulation Level:LI75 AC35/AC3 |
||||||||||||||||
| Rated power (KVA) |
Short-Circuit Impedance(%) | SC(B)H19 (W) | SC(B)H17 (W) | SC(B)H 15(W) | No-Load Current (%) |
Sound pressure dB(A) |
Weight (kg) |
Inner Dimension(mm) | Overall Dimension(mm) | |||||||
| No-Load Loss | On-Load Loss120ºC | No-Load Loss | On-Load Loss120ºC | No-Load Loss | On-Load Loss120ºC | L | W | H | L | W | H | |||||
| 30 | 4 | 50 | 640 | 60 | 640 | 70 | 710 | 0.6 | 60 | 640 | 1200 | 1000 | 750 | 1700 | 1350 | 2200 |
| 50 | 60 | 900 | 75 | 900 | 90 | 1000 | 0.5 | 60 | 720 | 1200 | 1000 | 790 | 1700 | 1350 | 2200 | |
| 80 | 85 | 1240 | 100 | 1240 | 120 | 1380 | 0.5 | 62 | 840 | 1300 | 1100 | 830 | 1700 | 1350 | 2200 | |
| 100 | 90 | 1415 | 110 | 1415 | 130 | 1570 | 0.5 | 62 | 920 | 1300 | 1100 | 860 | 1700 | 1350 | 2200 | |
| 125 | 105 | 1665 | 130 | 1665 | 150 | 1850 | 0.4 | 63 | 1050 | 1350 | 1100 | 900 | 1700 | 1350 | 2200 | |
| 160 | 120 | 1915 | 145 | 1915 | 170 | 2130 | 0.4 | 63 | 1180 | 1350 | 1110 | 900 | 1700 | 1350 | 2200 | |
| 200 | 140 | 2275 | 170 | 2275 | 200 | 2530 | 0.4 | 64 | 1480 | 1380 | 1100 | 980 | 1700 | 1350 | 2200 | |
| 250 | 160 | 2485 | 195 | 2485 | 230 | 2760 | 0.4 | 64 | 1510 | 1410 | 1100 | 1000 | 1800 | 1350 | 2200 | |
| 315 | 195 | 3125 | 235 | 3125 | 280 | 3470 | 0.3 | 66 | 1790 | 1540 | 1100 | 1030 | 1900 | 1400 | 2200 | |
| 400 | 215 | 3590 | 265 | 3590 | 310 | 3990 | 0.3 | 66 | 2150 | 1600 | 1100 | 1100 | 2100 | 1500 | 2200 | |
| 500 | 250 | 4390 | 305 | 4390 | 360 | 4880 | 0.3 | 67 | 2390 | 1650 | 1100 | 1230 | 2100 | 1500 | 2200 | |
| 630 | 295 | 5290 | 360 | 5290 | 420 | 5880 | 0.3 | 68 | 2650 | 1620 | 1200 | 1230 | 2100 | 1500 | 2200 | |
| 630 | 6 | 290 | 5365 | 350 | 5365 | 410 | 5960 | 0.3 | 68 | 2600 | 1620 | 1200 | 1230 | 2100 | 1500 | 2200 |
| 800 | 335 | 6265 | 410 | 6265 | 480 | 6960 | 0.3 | 69 | 3230 | 1780 | 1200 | 1290 | 2100 | 1500 | 2200 | |
| 1000 | 385 | 7315 | 470 | 7315 | 550 | 8130 | 0.2 | 69 | 3740 | 1870 | 1200 | 1430 | 2300 | 1500 | 2200 | |
| 1250 | 455 | 8720 | 550 | 8720 | 650 | 9690 | 0.2 | 71 | 4530 | 2000 | 1200 | 1480 | 2500 | 1500 | 2200 | |
| 1600 | 530 | 10555 | 645 | 10555 | 760 | 11730 | 0.2 | 72 | 5360 | 2130 | 1200 | 1610 | 2500 | 1500 | 2200 | |
| 2000 | 700 | 13005 | 850 | 13005 | 1000 | 14450 | 0.2 | 74 | 6250 | 2170 | 1300 | 1940 | 2600 | 1600 | 2200 | |
| 2500 | 840 | 15445 | 1020 | 15445 | 1200 | 17170 | 0.2 | 75 | 7320 | 2280 | 1300 | 2100 | 2600 | 1600 | 2200 | |
| Note: The above parameters are only for designing and selecting reference, and the final parameters are subject to the actual product. | ||||||||||||||||
Applications of Amorphous Metal Transformer
The 125kVA amorphous transformer excels in sustainability-driven scenarios:
Renewable Energy: Amorphous core transformers boost photovoltaic plant efficiency by 3%
Urban Grids: Amorphous metal transformers optimize residential power distribution with <30% nighttime load rates
Industrial Use: 24/7 operations in textile mills/data centers using amorphous steel core transformers save over $20,000 annually
Global Projects: IEC60076-certified amorphous transformers withstand Southeast Asia's tropical climates
Product Component
video
Why choose us?
GNEE strictly follows the comprehensive acceptance testing process to ensure that the performance of each device meets the standards. Our products and services have been successfully applied in more than 50 countries and regions around the world. As a trusted global industrial partner, we are always committed to helping customers achieve their sustainable development vision through high-quality products and full-process services.
Support
• Pre-sales: Free technical consulting, drawing review, and installation training.
• After-sales:
o Global warranty for 2 years; 5-year warranty on core components.
o 7×24-hour remote support, fault response within <24 hours.
o Operation manual provided.
Production environment
Our factory
