3000 Kva Pad Mounted Distribution Transformer

Henan GNEE Electric Co., Ltd. is one of the most reliable manufacturers and suppliers of 3000 kva pad mounted distribution transformer in China. With abundant experience, we warmly welcome you to wholesale high quality 3000 kva pad mounted distribution transformer at low price from our factory. Contact us for more cheap products.

The 3000 kVA pad-mounted transformer features a rigid barrier between the H.V. (High Voltage) and L.V. (Low Voltage) sections. A pressure relief device is installed on the top of the transformer's front cabin. When the internal pressure of the transformer becomes too high or abnormal, this device automatically releases the pressure to protect the transformer.On the high-voltage side, the transformer is equipped with a 5-position tap changer, a four-position loadbreak switch, 6 loadbreak bushing inserts, 6 HV bushing wells, and 3 elbow arresters. There are no fuse protectors on this side.

Key Features of the 3 MVA Transformer

Compliance: This 3 MVA transformer conforms to the CSA C227.4 Standard, ensuring that it meets stringent industry requirements. Moreover, its exceptional energy efficiency rating of 99.37% aligns with the CAN/CSA802.1 Standard, exemplifying its commitment to good performance.

Voltage Specifications: The industrial transformer boasts a primary voltage of 3-phase 27.6 kV, catering to specific needs. The secondary voltage configuration is 3-phase 600/347V, a voltage level tailored exclusively for deployment in Ontario, Canada.

Versatile Tap Changer: Equipped with a 5-position tap changer on the high-voltage side, this transformer offers flexibility by allowing adjustments to the high-voltage settings. These settings include 28.95 kV, 28.290 kV, 27.6 kV, 26.91 kV, and 26.22 kV, ensuring precise adaptation to varying operational requirements.

Safety and Utility Features: These 3 MVA transformers are designed with a 4-position loadbreak switch, three gauges without contacts, a pressure relief valve, and an oil charging and unloading valve, emphasizing safety, control, and operational convenience. It is important to note that no protection fuse is present within the system.
