Fiber Glass Covered Aluminum Wire

Shape：round
(1)Diameters：ranging from 2.0 to 7.0mm, which translates to 12 – 1 AWG or 14-1 SWG
Shape: retangular
(2)Sizes(mm): a:1-10,b:3-35
Conductor : aluminum


Fiber Glass Covered Aluminum Wire uses an aluminum conductor and achieves multi-layer insulation through successive coatings of insulating varnish and tightly wrapped glass fibers.

Glass fiber covered aluminum wire structure 1

Inner layer: Rectangular or round aluminum wire.
Middle layer: Coated with 0.2–0.5 mm of high-temperature resistant insulating varnish (polyesterimide or polyimide).
Glass fiber layer: Single or double-layer mesh-braided glass fiber wrapping.
Outer layer: A secondary high-temperature varnish coating that cures into a seamless insulation layer.

Fiber Glass Covered Aluminum Wire structure 2

Inner layer: Rectangular or round aluminum wire.
Glass fiber layer: Single or double-layer mesh-braided glass fiber wrapping.
Outer layer: A secondary high-temperature varnish coating that cures into a seamless insulation layer.

1.Enamels:
Diphenyl oxide of different temperature classes：130/155/180

2. Layers:
single and double

3.Insulation thickness(retangular):
(1)single
(2)double
(3)fiber and film covered

4.Standards:
IEC, NEMA, JIS, GB, such as IEC 60 317, NEMA MW 1000 or JIS C 3202

Double coated fiber glass covered aluminum round/flat Wire main dimensio

1.Conductor : aluminum
(1)High conductivity (2)Good solderability (3)High ductility

2.Shape：round
(1)Diameters：ranging from 2.0 to 7.0mm, which translates to 12 – 1 AWG or 14-1 SWG

Shape: retangular
(2)Diameters(mm): a:1-10,b:3-35

3.Enamels:
polyester:oil-modified:PETG:diphenyl oxide of different temperature classes：130/155/180

4.Layers:
single and double

5.Insulation thickness(retangular):
(1)single
(2)double
(3)fiber and film covered

6.Standards:
IEC, NEMA, JIS, GB, such as IEC 60 317, NEMA MW 1000 or JIS C 3202

Main dimension

Fiber Glass Covered Wire Properties:
(1)High voltage and temperature
(2)High resistance to abrasion
(3)Electromechanical properties
(4)Good adhesion, anti-moist

Fiber Glass Covered Copper Wire Applications:
transformer windings, motor windings, large and medium high-voltage electrical machine.

Rectangular Size Fiber Glass Yarn Covered Square Diameter Flat Glass Fiber Covered Aluminium Wire is mainly used in oil - immersed transformers & Motor Windings.
GNEE is professional China Fiberglass Insulated Wire Manufacturer, can produce Class 155, class 180 and class 200 enameled insulated wire is essential for high-temperature, demanding applications, offering durability and safety where traditional insulations fail. Its use spans industries requiring robust thermal and electrical performance.

Types of Fiberglass Yarn Coated Aluminium Wire

1.Glassfiber Covered Round Wire
2.Glassfiber Covered Flat Wire

[Q]: What's the temperature-resist grade of your enameled aluminum wire?
A : We produce the thermal class of enameled aluminum wire from 130 to 220 Centigrade.
[Q]: What is specifications of wire your company can produce?
A: 1. Enameled round aluminum wire: 0.25mm-6.50mm
2. Enameled flat aluminum wire: a: 0.80-10mm, b: 2.00-22.00mm
3. Enameled round copper wire: 0.10mm-6.00mm
4. Enameled flat copper wire: a: 1.00-6.00mm, b: 2.00-16.00mm
5. Kraft paper covered round wire: 1.00mm-7.00mm
6. Kraft paper covered rectangular wire: (a) 0.90 mm-10.00mm, (b) 2.00-35.00mm
7. Fiberglass covered Copper or Aluminum Round Wire Diameter: Φ1.0-Φ6.00mm
8. Fiberglass covered Flat wire Size (Aluminum): a: 0.90-6.30mm b: 2.00-25.0mm
Fiberglass covered Flat wire Size (Copper): a: 0.80-5.60mm b: 2.00-22.00mm
9. NOMEX paper covered rectangular wire: (a): 0.90mm-10.00mm Side (b): 2.00mm-16.00mm
10. Film covered rectangular wire: Side (a): 0.90mm-8.00mm Side (b): 3.00mm-25.00mm
